| Specification | Details |
|---|
| Operating System (OS) | Windows / iOS / Android |
| Image Sensor | CMOS |
| Image Resolution | 640 (H) x 480 (V) pixels |
| Light Source | Aiming: 625 nm LED; Illumination: 4000K LED |
| Scan Mode | Handheld (Manual) / Hands-free (Automatic) |
| Scan Rate | 300 scans/second |
| Scan Accuracy | 4mil @ Code39 |
| Print Contrast | 20% |
| Visual Indicator | Red and Blue LED Light, Buzzer |
| Interfaces | USB Keyboard, USB Virtual Serial Port, RS-232 |
| Scan Angle | Left/Right: ±55°, Front/Rear: ±55°, Rotation: ±360° |
| Field of View | 32° Horizontal, 24° Vertical |
| Transmission Mode | Wired Transmission |
| Dimensions (L x W x H) | 179 x 68 x 94 mm |
| Weight | 203g (with cable) |
| Cable | Standard 1.8M straight |
| Input Voltage | 5V DC ±5% |
| Working Current | 150mA |
| Scan Distance | 20-350mm @ EAN 13mil PCS=100%, 5-170mm @ QR 20mil PCS=100% |
| Operating Temperature | -20°C to +60°C |
| Working Humidity | 5% to 95% relative humidity, non-condensing |
| Storage Temperature | -40°C to +70°C |
| Electrostatic Protection | ±8 kV (Direct discharge) |
| Ambient brightness | 0~100,000 LUX |
| IP Rating and Drop Resistance | IP54 and 2M |
| Safety Regulations | CE (EN 55032:2015; EN 55035:2017), ROHS, EN62368-1:2014+A11:2017, FCC PART 15 CLASS B |
| Supported 1D Barcodes | EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code11, MSI-Plessey, Standard 2 of 5, Plessey, China Post, Code 16K, GS1 Databar (RSS-Expand, RSS-Limited, RSS-14, GS1 Composite) |
| Supported 2D Barcodes | QR, PDF417, DataMatrix (ECC200), Aztec, HanXinCode, Maxicode, Micro QR, Micro PDF417 |
